1. High efficiency and energy conservation;
2. No-board connection;
3. Chrome hammer and special impact plate;
4. Cubical shape of final product and the output size is adjustable;
5. Easy maintenance.
| Model |
Rotor (Mm) |
Feeding Size (Mm) |
Max Feeding Size (Mm) |
Capacity (T/H) |
Motor(Kw) |
Weight (T) |
Dimensions (Mm) |
|---|---|---|---|---|---|---|---|
| PF-1007 | Φ600 | 720×400 | 300 | 30-50 | 37-55 | 9.3 | 2370×1540×2630 |
| PF-1010 | Φ600 | 1070×400 | 300 | 50-80 | 55-75 | 11.6 | 2400×2250×2630 |
| PF-1210 | Φ900 | 465×1160 | 350 | 70-120 | 110-132 | 14.5 | 2640×2370×2890 |
| PF-1214 | Φ900 | 465×1500 | 350 | 90-160 | 132-160 | 17.16 | 2640×2720×2890 |
| PF-1315 | Φ900 | 990×1600 | 500 | 120-200 | 160-200 | 20.2 | 3510×3040×3020 |
| PF-1415 | Φ1200 | 1145×1520 | 650 | 200-260 | 220-315 | 27 | 3745×3022×3519 |
| PF-1520 | Φ1200 | 830×2050 | 700 | 220-450 | 315-440 | 38.7 | 3581×3560×3265 |
