2. Equipped with powerful diesel engine. The stronger overall working arm is equipped with big cylinders. Its maximum lifting force is more than 3000kgs. The maximum working flow is 140L/min.
| Model | HC100V | HC120V |
| Operating Load (kg) | 1200 | 1500 |
| Max. Speed (km/h) | 12 | 12/18 |
| Hydraulic flow (L/min) | 75 | 75 |
| Max. Working Flow (L/min) | 120 | 140 |
| Tire Model | 12-16.5 | 12-16.5 |
| Rated Power (kW) | 74 | 103 |
| Fuel tank Volume (L) | 100 | 100 |
| Self Weight (kg) | 4500 | 4600 |
| Bucket Volume (m³） | 0.5 | 0.55 |
Note: Our products are being updated constantly, all rights reserved by HAMAC.
Structure Data:
| Main data/Model | HC100V | HC120V |
| Overall operating height (mm) | 4250 | 4250 |
| Height to bucket hinge pin (mm) | 3250 | 3250 |
| height to top of cab (mm) | 2160 | 2160 |
| Height to bottom of level bucket(mm) | 3083 | 3083 |
| Overall length without bucket(mm) | 3100 | 3100 |
| overall length with bucket(mm) | 3800 | 3800 |
| Dumping angle at maximum height(° ) | 40 | 40 |
| Dumping height(mm) | 2500 | 2500 |
| Dumping reach(mm) | 750 | 750 |
| Rollback o bucket on ground(° ) | 25 | 25 |
| Rollback of bucket at full height(° ) | 124 | 124 |
| Wheelbase(mm) | 1115 | 1115 |
| Ground clearance(mm) | 210 | 210 |
| Angle of departure(° ) | 20 | 20 |
| Front turning radius without bucket(mm) | 1250 | 1250 |
| Front tuning radius(mm) | 2112 | 2112 |
| Rear tuning radius(mm) | 1992 | 1992 |
| Rear axle to bumper (mm) | 1302 | 1302 |
| Tread width, centerline to centerline (mm) | 1500 | 1500 |
| Width (mm) | 1880 | 1880 |
| Bucket width (mm) | 2030 | 2030 |
