1.Higher capacity and less wear costs.
2.Wide range of application suitability.
3.Easy to maintain, reduce the downtime and maintenance costs.
4.Stable running performance and easy operation.
5.Stable bevel wheel transmission device
6.Balanced runout rotation ensures best capacity.
7.Proper operation, continuously loading until the machine shuts down as scheduled.
| Model | Moving Cone Diameter(mm) | Feeding Size (mm) | Max Feed Edge(mm) | Discharge Range (mm) | Capacity (t/h) | Motor (kw) |
|---|---|---|---|---|---|---|
| PYB600 | Φ600 | 75 | 65 | 12-15 | 40 | 30 |
| PYD600 | Φ600 | 40 | 35 | 3-13 | 12-23 | 30 |
| PYB900 | Φ900 | 135 | 115 | 15-50 | 50-90 | 55 |
| PYZ900 | Φ900 | 70 | 60 | 5-20 | 20-65 | 55 |
| PYD900 | Φ1200 | 50 | 50 | 3-13 | 15-50 | 55 |
| PYB1200 | Φ1200 | 170 | 145 | 20-50 | 110-168 | 110 |
| PYZ1200 | Φ1200 | 115 | 100 | 8-25 | 42-135 | 110 |
| PYD1200 | Φ1200 | 60 | 50 | 3-15 | 18-105 | 110 |
| PYB1750 | Φ1750 | 250 | 215 | 25-50 | 280-480 | 160 |
| PYZ1750 | Φ1750 | 215 | 185 | 10-30 | 115-320 | 160 |
| PYZ1750 | Φ1750 | 100 | 85 | 5-13 | 75-230 | 160 |
| PYB2200 | Φ2200 | 350 | 300 | 30-60 | 590-1000 | 280/260 |
| PYB2200 | Φ2200 | 275 | 230 | 10-30 | 2000-580 | 280/260 |
| PYD2200 | Φ2200 | 130 | 100 | 5-15 | 120-340 | 280/260 |
